Strip Cross Crack Assistant

The Strip Cross Crack Assistant is a digital tool designed for detecting strip cross cracks, aiding operators, quality managers, and production managers in aluminum or steel rolling mills. It helps achieve high-quality strip production, minimize downtime due to defects, and improve overall plant efficiency. The assistant increases automation in strip crack detection and enhances monitoring processes with augmented video streams. It also provides real-time alerts and confidence levels for detected cracks through automatic evaluation using machine learning, featuring augmented video streams with marked cracks and confidence levels.

The Strip Cross Crack Assistant marks a significant advancement in detecting and managing strip cross cracks within the steel rolling process. Utilizing artificial intelligence, this system offers a robust solution to a critical challenge faced by rolling mill operators globally. The detection process begins with high-resolution cameras positioned at the exit of the roughing mill, capturing continuous video streams of the moving strip, providing real-time visual data essential for crack detection.

The system uses sophisticated machine-learning models trained on historical video recordings of strips, both with and without cracks. These models are designed to recognize specific patterns and anomalies indicative of strip cross cracks. The training process involves supervised learning techniques, where the model is fed labeled data, allowing it to learn the distinguishing features of cracks over numerous iterations.

As the strip passes through the roughing mill, the AI system processes each frame of the video stream in real-time. It applies the trained model to detect potential cracks by analyzing the strip's surface texture and identifying deviations from the norm. Advanced image processing algorithms enhance detection accuracy, even under varying lighting conditions and strip speeds.

Upon detecting a strip crack, the system generates an augmented video stream featuring visual markers like colored frames around detected cracks, providing immediate visual alerts to operators. The augmented display includes a confidence level for each detection, indicating the probability that the identified feature is indeed a crack, helping operators make informed decisions about necessary actions.

The system automatically classifies strips based on the presence and severity of detected strip cracks. Strips with significant defects are flagged for removal before entering the finishing mill, preventing potential damage and quality issues. Operators can configure alerts in various formats, such as pop-up messages or audio alarms, ensuring critical information is communicated effectively and promptly.

Detected strip crack data, including images and analysis results, can be transmitted via Ethernet to a centralized database or directly to quality management systems, facilitating comprehensive reporting and traceability and supporting continuous improvement initiatives. By integrating the Strip Cross Crack Assistant into rolling mill operations, aluminum and steel producers can significantly enhance their quality control processes. This AI-driven solution not only improves detection accuracy but also streamlines decision-making, ensuring only the highest quality materials proceed through the production line. The result is a more efficient, reliable, and cost-effective production environment that meets the stringent demands of modern aluminum and steel manufacturing.

Benefits of Strip Cross Crack Assistant

• Enhanced quality control: maintains high material quality by preventing cracks from entering the finishing mill.

• Improved efficiency: minimizes downtime and material waste by automating the crack detection process.

• Operational safety: reduces the likelihood of system damage by ensuring timely crack detection and removal.

• Augmented monitoring: provides operators with an augmented video stream, highlighting detected cracks with confidence levels and system time.

• Real-time detection: instantly identifies strip cross cracks, reducing the risk of defects spreading.

Features of Strip Cross Crack Assistant

• Machine learning integration: utilizes historical data to train models for precise crack detection.

• Augmented video stream: displays marked cracks with signal colors and confidence levels for easy identification.

• Configurable alerts: allows customization of alert types and display settings to suit operational needs.

• Connectivity: enables seamless transmission of detection data to relevant stakeholders.
